ECTFE-GK Sheets for Jincheng Petrochemical Flue gas ducts
Installation Date: 2016
Product: ECTFE fabric backed sheets 2.3mm
Application Area: ECTFE/FRP Duct
Description: Clean gas outlet duct from WSA Condenser
Pipe dimensions: 1800 mm diameter, 150 m length
Temperature: 95°C (operation), 120°C (design)
Medium: Flue gas, 10 kpa design pressure
Process Treatment: Alkylation spent acid regeneration
Process Gas Flow: 100,000 Nm3/h
Engineering: Haldor Topsoe & Tialoc
Location: Zibo city, Shandong Province, China
ECTFE Lining FRP Stack & Exhaust Pie
In the chimney and ventilation ducts SO2 and SO3 react to produce high concentrations of H2SO3 and H2SO4 with high temperatures. ECTFE has an excellent chemical resistance against all kinds of acids. That’s why the customer chose ECTFE. The integrated glass fiber provides a high bonding strength with the FRP, which ensures the safe operation of the system even under vacuum.
ECTFE Lining CS Tanks for Ballast Water Treatment System for Ecochlor
We made 7 tanks for the 1st year; the tanks’ volumes are different from 3 m3 – 6 m3. Now all of tanks are qualified by the customers.
AT&S Chongqing HDI PCB Project
AGRU supplied PP pipes and fittings for WWT system, HDPE pipes and fittings for PDS, PPs pipes, fittings & valves for the ventilation system. PPs piping which bigger than 315mm are machined from our PPs sheets. AGRU
Yieh Phui 1 Million tons pickling and cold-rolling Project
AGRU supplied all PP & PVDF pipes & fittings for this project. For > 355mm ventilation pipes are machined from our PPH sheets. The pictures are 2 years after installation and no problems.
